LSD-High pressure sludge deep dewatering system

Working principle:

The high pressure belt sludge deep dewatering system can continuously dewater the sludge twice. The dehydrated sludge (moisture content of about 80%) goes into the sludge mixer for full mixing with modifier and curing agent Mixing, The sludge to achieve wall breaking, electrical neutralization, change the characteristics of sludge, reduce the specific resistance of sludge dewatering, mixed sludge into In the sludge distribution system of the high-pressure belt type deep sludge dehydrator, the sludge is evenly distributed over the filter cloth, and the sludge passes through the pressure section of the high-pressure belt machine.A series of pressing and dewatering of medium pressure area, high pressure area and auxiliary press roller can reduce the moisture content of sludge to 60% (according to project requirements)Below 70%) for the subsequent drying or incineration of sludge to provide convenience.

Technical character:

1. It can directly connect with the original sludge dewatering system.

2. Fully enclosed structure, sludge does not fall, the environment is clean and hygienic.

3. Continuous operation, high degree of automation, simple operation, convenient maintenance.

4. Low mud inlet, convenient connection, small footprint, convenient layout,

5. Low operation cost and low maintenance cost.

6. The dehydrated sludge has good stability and will not be diluted again after meeting water.

7. Stable heavy metals and less bacteria.
