SST series screw type sludge thickener

Working principle：

The concentrated body of the volute sludge thickener consists of a fixed ring and an active ring. the main part is a screw shaft .lt integrates the automatic control cabinet, flocculation disposal tank, sludge concentration part and complete tank in one, under the conditions of fully automatic operation, continuously complete the sludge concentrate by Sludge and flocculant by mechanical mixing fully and react to form 3- 5mm floc, gravity into the concentrated body; In the concentrated part, the sludge continues to move forward with the rotation of the screw shaft, the volume of the main chamber is continuously compressed, and the filtrate is filtered out flocculation, Sludge solid content gradually increased to achieve rapid concentrate sludge; As the rotation of the screw shaft will drive the movement ring and the fixed ring rapidly concentrate, a device to achieve a continuous self-cleaning process. to avoid block problem of the traditional equipment. The stacker concentrator can be used as pretreatment equipment for sludge dewatering and deep dewatering systems. Presses, high-pressure diaphragm panels or other dewatering equipment.

Technical character：

1. Concentrated sludge range, suitable for water content range of 95% -99.8%

2. After the concentration of sludge in the range of 90-96%

3. High efficient concentration, small place

4. No filter cloth, self-cleaning, no cogging, without high-pressure backwash water

5. Enclosed operation, reduce odor

6. Less vulnerable parts, low maintenance costs, long service life

7. Automatic control, continuous operation, easy maintenance and management
